ADC120S-12/24

(12 or 24 VDC Commercial Connector 简易接头 25° Rotation 25° 转角 Serrated Shaft 花键轴)
The 120 SERIES electric actuator is a rotary output, linear torque, proportional servo. This electromechanical actuator is typically used as an engine fuel control positioning device. An internal spring provides fail safe operation by forcing the actuator to the fuel shut off position when the actuator is de-energized. This design combines fast operation, multi voltage usage, wider rotation angle, and proven reliability. The actuators can operate directly on 12, 24, or 32 volt battery supplies

资料下载:
\Installation Manual


    CH1203 12' Harness - Straight Connector (MIL)
    CH1210 12' Harness - 90º Connector (MIL)
    CH1212 30' Harness - Straight Connector
    CH1215 6' Actuator Mating Half - Packard Connector
    EC1000 Mating Connector - Straight - MIL
    EC1110 Mating Connector -
    EC1300 Mating Connector - Packard
    LE1500-1 4.3" - 3/16" Holes / Smooth Shaft
    LE1500-2 4.3" - 1/4" Holes / Smooth Shaft
